130hp 4x2 Emergency Rescue Fire Truck , Small Fire Tender With Fire Fighting Equipments
| Place of Origin | CHINA |
|---|---|
| Brand Name | IVECO |
| Certification | CCC(F) |
| Model Number | WHG5041TXFJY10E |
| Minimum Order Quantity | 1 |
| Packaging Details | \ |
| Delivery Time | 90days |
| Payment Terms | L/C, T/T |
| Supply Ability | 500unit |
Product Details
| Fuel Type | Diesel | Condition | New |
|---|---|---|---|
| Emission Standard | Euro 3,Euro 4,Euro 2,EURO 5 | Horsepower | 130HP |
| Size | 6560×2000×3010 | Type | Rescue,Fire Fighting Truck |
| Color | Red | Drive Type | 4*2 Left Hand Drive Or Right Hand Drive |
| Product Name | 4x2 Fire Fighting Truck,fire Fighter Truck,new Fire Truck | Name | Fire Rescue Truck |
| Chassis | IVECO/SITRAK/ISUZU/Dongfeng/foton | Warranty | 12 Months |
| Highlight | Emergency Rescue Fire Truck 130hp,Emergency Rescue Fire Truck Small,4x2 Small Fire Tender |
||
Product Description
IVECO brand 130hp 4*2 small Fire Rescue Vehicle Factory Sale with fire fighting equipments
I,Main Product Specifications
| Product Name | IVECO Emergency Rescue Fire Truck | ||
| Model | WHG5041TXFJY10E | ||
| Chassis parameters | Chassis Model | NJ1054AGCS | |
| Overall dimensions (mm) | 6560×2000×3010 | ||
| Gross weight (kg) | 4110 | ||
| Passengers in cab | 6 | ||
| Wheelbase | 3600 | ||
| Engine model | SOFIM8140.43S4 | ||
| Engine power(kw) | 95 | ||
| Powder density | 23.114 | ||
| Emission standard | EURO 4 | ||
| Displacement (ml) | 2798 | ||
| Max speed(km/h) | 125 | ||
| Fire performance | Generator | Model | SHT11500 |
| Rated Power(kw) | 10 | ||
| Lifting lamp | Bocan GSD-Z04/7000/4 | ||
| Maximum height of lifter(m) | ≥5 | ||
II,Main characteristics
- With functions of lifting ,self rescue, pulling ,obstacle clearance ,generating lighting,etc.
- Can be equipped with a large number of demolition,detection ,leakage stoppage, protection and other fire equipments or tools.
- Ideal rescue fire fighting vehicle for public security fire forces and petrochemical, oil transportation terminal, airport and other full-time fire brigades
III,Basic Description
JY80 emergency rescue fire truck is equipped with the original U.S. champion electric winch N16800XF; it adopts Honda generator SHT11500; the roof is equipped with lifting lighting system YZH4-5.04CA; and the rear is equipped with a hydraulic truck crane SQ5ZK2 produced by XCMG. The equipment compartment adopts the structure of rotation and pulling, which has a high integration degree, and is convenient to use.
This vehicle has a novel appearance, reasonable layout, and convenient operation, which makes it more close to the needs of the actual rescue, and it is a necessary and ideal rescue fire fighting vehicle for public security fire forces and petrochemical, oil transportation terminal, airport and other full-time fire brigades.
